Custom Builds

Off Road Accommodation

Our design team has years of experience living and managing off-road commercial caravan camps throughout Australia ….

“We know what works and more importantly what does not…”



This knowledge is built into every commercial RED ROCK caravan we build – strength and reliability are at the forefront of design.

Our Red Rock industrial caravan features include;

Chassis

  • Heavy duty Dura Galv chassis (4mm x 150 x 50)
  • Professionally engineered Mega-Duty RTC hitch plate
  • Off-road 4,500kg rated double rock ‘a suspension
  • High ground clearance and Dove Tailed for creek crossings.
  • Aerodynamic nose cone – reducing fuel use by 10% and improving towing performance, stability and strain on towing vehicle and drive train.
  • High Quality – Pirelli Scorpion AT Light Truck tyres LT235/85 with Mine Spec 16’’  Toyota Landcruiser or Ford Ranger rims
  • 12’’ AL-KO electric braking system with Break Away and Controller system
  • Dual solid 50mm Axels – rated at 4,500kg (2 x 2,250kg)
  • Licensed at 3,500kg – constructed to 4,500kg specifications (optional 50mm or 70mm tow hitch)
  • 4 x Stabilisers – wind down to insure quick setup
  • Heavy-duty galvanised fold away steps to each room
  • Body constructed of 50mm insulated wall panels for strength & energy efficiency
  • R10 Rated Industrial flooring (15mm structural ply with 4mm industrial vinyl

240V AC

  • Mine Spec electrical installation.
  • Low ‘test & tag’ design features
  • Clipsal – Australian double pole GPO’s and switches fitted throughout (USB outlets optional)
  • LED External lighting (IP65), LED Internal Lighting
  • Lockable Power distribution board – flush mounted & water proof (IP66)
  • Separate electrical isolation fitted to each air conditioning unit
  • Weather Proof (IP65) external light switches & external GPO’s

12v DC

  • Powder coated aluminium mounted, LED Narva, Series Brake & indicator lights
  • Aluminium mounted, US built LED clearance lights
  • Industrial 7 Pin plug with Narva 7 wire cable
  • 12v Electrical brake control & emergency brake away system
  • 12v Anderson inlet for brake battery backup

Contact Information

From temporary exploration, construction camps to accommodation overflow due to mining shutdowns, our remote turnkey camps offer a comfortable and enjoyable space to live throughout the life cycle of your project.
